Acrel ATP Series Remote Temperature Monitor Touchscreen

Name: ATP Series Remote Temperature Monitor Touchscreen
Brand: Jiangsu Acrel Micro-grid Research & Development Institute

ATP series wireless temperature measurement centralized acquisition touch screen is suitable for temperature monitoring of high-voltage switch cabinet contacts and contacts, knife switch, high-voltage cable intermediate head, dry-type transformer, low-voltage and high-current equipment. The touch screen can be used in conjunction with a wireless temperature measurement transceiver to achieve data collection of 240 wireless temperature measurement sensors. The matching sensors include ATE100M, ATE100, ATE200, ATE100P, ATE200P, ATE400, etc.

Specification of ATP Series Remote Temperature Monitor Touchscreen

Parameters

Items		Features
Type of touchscreen		ATP007,ATP010
Power source		DC 24V（±10%），15W
Points of temperature		240 points
Range of temperature		-50℃~125℃
Precision		±1℃
Battery life		≥5 years
Communication	Interface	RS485/Ethernet
	Protocol	Modbus-RTU/ Modbus-TCP
Environment	Temperature	-10℃~55℃
	Humidity	≤95%
	Altitude	≤3000m

Features of ATP Series Remote Temperature Monitor Touchscreen

The exchange between the wireless temperature sensor and the transceiver is transmitted through wireless signals, which will not affect the insulation performance of the system, making it safer to use;

The device has the characteristics of complete isolation, convenient installation, strong anti-interference ability and reliable operation, which solves the safety problem of contact temperature monitoring under high voltage state;

It is possible to configure parameters such as alarm and communication of the monitoring module. There are 2 RS485 and 1 Ethernet interfaces, through which the transmission ring can be monitored.
